BUTTONS AND PUSH BUTTONS

INELCA CONTROLS cabin and landing buttons are designed to meet the needs of each customer and installation, adapting both dimensions and designs and complying with current regulations.
We have four standard models, two of surface AIDA and FLORENCE and two flush ITALIA and ITALIA SOFT as well as full panel in the cabin.
Our high quality, resistent, reliable and durable push buttons offer a sophisticated design. Our standard round model, Venus Monolight, can be supplied with blue or red light. We have other models: square, vandal-proof, light of another color, gold, etc…
Ask for more information.
24Vdc push-buttons with directional arrows.
Push buttons with light or light/acoustic indication.
Recessed buttons in panel, surface or column keypad.
Custom Anagrams.
Display, 3 ”or 5” blue LCD, or 4.3 ”or 7” color TFT.
Emergency ceiling.
Presence lights (IS), open door, busy (Universal).
Pre-directional arrow modules for cabin and landing.
Merak, 3 Bymesa or customer bidirectional communication device according to current regulations.
Wiring and verification of cabin and landing buttons (Optional). Emergency Module + Alarm - ROSAVERDE.

WARNINGS FOR CLEANING
Our push buttons and fixtures must be cleaned only and exclusively with a COTTON RUG and WARM WATER.
Avoid every use of chemical substances, above all for plastic o metallic surfaces. Most of our products are made in polycarbonate, ABS, methacrylate or Nylon 66. The use of many cleaning products with caustic soda, hydrocarbons, hydrochloric acid, nitric acid, acetic acid, ethyl alcohol and methyl alcohol are strictly prohibited.

ITALIA SOFT
Flat flush button panel for cabin and landing.

MAIN FEATURES:
Types: 2 mm thick flat stainless steel button panel.
Widths: 75-96-185-200 mm.
Optional: plastic box or zinc coated.
Finishes: scotch brite or polished steel, satin PVD or polished gold, polished blue.
Fixation: by means of visible screws.
New fixation: by means of bolts, without visible screws. Optional box:

ITALIA
Flat flush button panel for cabin and landing.

MAIN FEATURES:
Types: 2 mm thick flat stainless steel button panel.
Widths: 75-96-185-200 mm.
Optional: plastic box or zinc coated.
Finishes: scotch brite or polished steel, satin PVD or polished gold, polished blue.
Fixation: by means of visible screws.
New fixing: by means of bolts, without visible screws. Optional box:

FLORENCE
Landing button panel and surface cabin, ideal for modernisations.

MAIN FEATURES:
Surface model
1.2 mm thick embedded steel plate.
Suitable for restructuring.
3 available widths: 101, 201 or 300 mm (1.5 mm thick).
Ask for other dimensions.
Fixing system of wall mounting, without cuts or patches.
Stainless steel finishes, optional: mirror gold PVD, satin gold PVD, scotch.

AIDA
Landing button panel and surface cabin, ideal for modernisations

MAIN FEATURES:
Suitable for restructuring.
4 available widths (65, 85, 101, 201 mm).
Fixing system of wall mounting, without cuts or patches.
Stainless steel finishes, Scotch brite, stainless steel. mirrored, scotch brite gold, mirror gold. Embellished in chrome or gold zamak.
Flat bezel (AIDA STANDARD) available for all types.
Folded steel plate of 1.2 mm thick for width 201.
Folded steel plate of 1 mm thick for widths 65, 85, 101.

COLUMNS

Full height cabin columns suitable for modernisations.
AIDA column with key / AIDA column with screw fixation / FLORENCE column with key / FLORENCE column with screw fixation

PUSH BUTTONS
VENUS 2.0* BUTTONS * Blue or Red Light / Round Hoop / Satin Stainless Finish

* Ask for other models (square, vandal-proof ...)
´
MAIN FEATURES:
Body: polycarbonate button with embossed symbol (EN 81-70 standard) and in Braille.
Rings: galvanized ABS (gold or chrome) or stainless steel.
Mounting: the button is placed inside a cutout (Ø 32.2) from the front and fixed using a threaded ring.
Thickness of the front plate: 0.7 mm to 5 mm.
Cover: polycarbonate with AISI 304 stainless steel or finished in gold / black PVD coating; tactile legend (s) (embossed) and illuminated.
Contacts: 1 micro switch 2 micro switch.
Wiring: Connectors with screws or prewired (AMP, JST or minispox).
• Lighting: Led 12V or 24V DC 20mA.
Pressure: 1.2 mm.
Average life: 2,000,000 activations.
Degree of protection: IP51.
Ask for more information
