Displays, stand-alone displays and accessories

WARNINGS FOR CLEANING
Our push buttons and fixtures must be cleaned only and exclusively with a COTTON RUG and WARM WATER.
Avoid every use of chemical substances, above all for plastic o metallic surfaces. Most of our products are made in polycarbonate, ABS, methacrylate or Nylon 66. The use of many cleaning products with caustic soda, hydrocarbons, hydrochloric acid, nitric acid, acetic acid, ethyl alcohol and methyl alcohol are strictly prohibited.

IRIS 7”
7 inch TFT display

MAIN FEATURES
  • Easy configuration via software or computer.
  • Update via SD card.
  • Customizable background, arrows, plants, logo and signage.
  • UNI EN 81-70.
  • Customizable background with images and sounds (for cabin position indicators). Power saving mode (stand-by).
  • Simple keyboard for the selection of the main features (buzzer volume, communication interface, first floor, brightness, stand-by duration).
  • Built-in emergency light.
  • Communication interface: serial Vega, RS485, CAN, parallel and magnetic sensors •
  • Mounting: protection box.
  • Mounting: horizontal and vertical.
  • On-board voice synthesizer (IRIS 7"only).
  • Calendar and temperature.
Visible area: 7": 154.1 x 86 mm. Occupied area: 7": 178 x 166 mm.
Resolution: 800 (RGB) x 480 -WVGA Pixel (mm): 0.1926 x 0.1179 mm
Colours: 16 m.
Power consumption: 360mA.
Power supply: 12 ÷ 24 Vcc ± 10%.
Temperature range: -20/+ 70°C.
Optional: IRIS 7'' VANDALISM PROOF: 10 mm glass thickness.

IRIS 4.3”
4.3 inch TFT display (vertical and horizontal)

MAIN FEATURES
  • Easy configuration via software and computer.
  • Update via SD card.
  • Customizable background, arrows, plants, logo and signage.
  • UNI EN 81-70.
  • Customizable background with images and sounds (for cabin position indicators).
  • Power saving mode (stand-by).
  • Simple keyboard for the selection of the main features (buzzer volume, communication interface, first floor, brightness, stand-by duration).
  • Built-in emergency light.
  • Communication interface: serial Vega, RS485, CAN, parallel and magnetic sensors. Mounting: protection box.
  • Mounting: horizontal and vertical.
  • Calendar and temperature.
  • Voice synthesizer.
Dimensions: 147 x 79 mm. Occupied area: 160 x 80.
Visible area: 95.3 x 53.8 mm.
Housing: 95.3 x 53.8 mm (R3.15).
Resolution: 480 (RGB) x 272 -WVGA. Pixel (mm): 0.198 x 0.198mm.
Colours: 65,000.
Power Consumption: 220mA.
Power supply: 12/24 Vcc.
Temperature range: -20/70°C.
Parallel version (1 pole inputs per floor): prewired connectors.
Wiring: prewired connectors.
Optional: IRIS 4.3 '' VANDALISM PROOF: 10 mm glass thickness.

TRICOLOR
5 inch Blue LCD Display with or without chrome trim

MAIN FEATURES
  • LCD model: LCD indicator for cab available in blue background.
  • Quick assembly: front with frame or surface kit in 1.2 mm keypads and 2 mm buttons by means of welded bolts.
  • Screen: transparent polycarbonate (shock and impact proof).
  • Colours: White LED on blue background.
  • Wiring: threaded or pre-wired connectors (AMP or JST).
  • Common: positive or negative.
  • Power supply: 12/24 Vcc +/- 10%.
  • Signs: plants, arrows, out of service and overload signals.
  • Optional signals: alarms sent and confirmed (yellow and green) and red overload signal. Available characters: programmable characters in Latin, Cyrillic and Greek alphabet. Integrated and programmable three-tone gong.
  • Easy programming through a dedicated integrated keyboard.
  • 32 stops in binary code, 14 stops 1 pole per floor.
  • 64 stops in independent mode (magnetic sensors).
  • Up and down arrow (41mm).
  • OPTIONAL - Vandalism-proof glass for surface mounting.
  • OPTIONAL - Chrome frame

Ask for more information

ICARO
Blue LCD Display 3 inches with or without chrome trim

MAIN FEATURES
  • LCD model: LCD indicator available in blue background.
  • Quick assembly: front with frame or surface kit in 1.2 mm keypads and 2 mm buttons with welded bolts.
  • Screen: transparent polycarbonate (shock and impact proof).
  • Colours: White LED on blue background.
  • Wiring: threaded or prewired connectors (AMP or JST).
  • Common: positive or negative.
  • Power supply: 12/24 Vcc +/- 10%.
  • Signs: plants, arrows, out of order.
  • Optional signals: alarm sent and overload.
  • Integrated and programmable three-tone gong.
  • Easy programming through a dedicated integrated keyboard.
  • 32 stops in binary, 11 stops 1 pole per floor.
  • Up to 64 stops in independent mode (magnetic sensors).
  • Up and down arrow (40.5 mm).
  • OPTIONAL - Vandal-proof glass for surface mounting.
  • OPTIONAL - Chrome frame.

Ask for more information.

STAND-ALONE DISPLAYS KITS

STAND-ALONE DISPLAYS KITS

Our STAND-ALONE DISPLAYS KITS can be installed in any elevator autonomously. A stand kit, 2 magnetic fingers NO and two magnets of 100mm per plant and initial one of 200mm. If you do not have 24VCC in the cabin, a sealed box power supply will be supplied to be connected to the 220VAC of the cabin lighting.
You only have to choose the display model you want:
  • TFT IRIS 4.3”* (In vertical or horizontal)
  • TFT IRIS 7”* (In horizontal)
  • ICARO LCD 3” **
  • LCD TRICOLOR 5 ”**
* Flush mounting with stainless plate and countersunk holes or bolts
** Flush mounting with stainless plate and countersunk holes or bolts or with chromed frame without bolts if a moderately clean die is achieved in the existing keypad (+-4mm).

EMERGENCY LIGHTS

EL_LINE
Cabin emergency light.
Compliance with EN81-20/50

MAINFEATURES
  • STRUCTURE: High resistant polycarbonate structure for EN81-71 and EN81-72. ASSEMBLY: Fixing by means of bolts welded on plate and nuts.
  • PLATE THICKNESS: 1 to 3 mm.
  • WIRING TYPES: Terminals.
  • LIGHTING: white - 6 LEDs of high brightness.
  • POWER SUPPLY: 12 / 24V dc. POWER SUPPLY: 12V-100mA; -24V 50mA. PROTECTION RATING: IP54

LEM01
Cab emergency light.

MAIN CHARACTERISTICS
  • Area: 124 x 60 mm.
  • Trimming: 144 x 79 mm.
  • Power supply: 12-24 Vcc +/- 10%.
  • Signals: alarms sent and received.
  • Possibility of inserting the logo and elevator information.
  • Compatible with the design of the TRICOLOR LCD.

LEM00
Cab Emergency Light

MAIN CHARACTERISTICS
  • Area: 124 x 60 mm.
  • Trimming: 144 x 79 mm.
  • Power supply: 12-24 Vcc +/- 10%.
  • Compatible with the design of the TRICOLOR LCD.

EL01
Small cabin emergency light

MAIN FEATURES
  • Power: 1 Watt
  • Power supply: 12-24 Vcc
  • Compatible with the ICARO LCD design.

VENUS LEM
Round emergency light.

MAIN FEATURES
  • Body: polycarbonate button with integrated emergency white light.
  • Bezel: Metallic ABS (gold or chrome) or stainless steel.
  • Mounting: the emergency light is placed within a Ø 32.2 cutout from the front and fixed using a threaded ring.
  • Thickness of the front plate: 0.7mm to 5mm.
  • Wiring: prewired connectors (12V or 24V) or with screws (12V and 24V).
  • Degree of protection: IP51 or IP54.
